Product Details
- Brand: AUBIG
- Dimensions: 3.15" h x
9.06" w x
12.60" l,
1.10 pounds
Features
- Automatic change to backup view when on reverse position, even the monitor is turned off
- Camera uses SHARP 1/3" high-resolution CCD and wide field of view lens
- Built in high-powered IR LED for night vision function
- 9" stand-alone rear view LCD monitor with Sunshade design
- Built-in quad control box function ,Support four camera inputs ,Single View/Split view/Quad view selectable
7 Inch Car Rear View System Quad TFT/LCD Video Monitor Night Vision Backup Camera for RV, Truck, Trailer, Bus, Fifth-Wheel
Product Description
This car rear view system is complete with a crystal clear 9" TFT LCD COLOR monitor with mirror image capability,the Resolution is 800 x (RGB) x 480dots, a 2 channel multiplexer (can connect a dvd player or other cameras) with automatic system switch, 108degrees CCD camera with 50 foot infra-red night vision and all the wires, connectors and mounts you will need. The system is completely weather proof with a IP66 rating, strong and reliable, shock resistant with a 10G impact rating (highest in the industry) and comes with a full year warranty.
Sunshade design
Built-in quad control box function
Support four camera inputs
Single View/Split view/Quad view selectable
7 languages OSD display
PAL/NTSC optional, MIRROR/NORMAL image optional
Automatically turn on when the reversing gear is engaged
With high-low voltage protection and short circuit protection
Power : 12~24V
Trigger priority : CAM 1>CAM 2>CAM 3>CAM 4
CCD
Images Sensors : 1/3" SHARP COLOR CCD
TV System : NTSC
Effective Pixels : 512 x 582/512 x 492
Sensing Area(mm) : 4.9 x 3.7
Resolution(TV Lines) : 420
Min.illumination(Lua/F1.2) : 0
Horizontal Sync.Frequency(KHZ) : 1/50 or 1/60 ~ 1/10,000
Vertical Sync.Frequency(HZ) : 15.625/15.734
Video Output : 1Vp-p,75 Ohm
BLC : Auto
S/N ratio : Better than 48dB
Lens : F=2.8mm/F=2.0
Lens Angle(Deg.) : 108
Current Consumption(mA) : 290
Power Supply(DCV) : 12
Operating Temperature(Deg.C) : -20 ~ +70(RH95%Max.)
Storage Temperature(Deg.C) : -40 ~ +80(RH95%Max.)
Dimension : 75 x 43 x 57mm
Packing :
Gift box.Size : 10.1 x 6.5 x 10.1 CM
Gift box .WT : 0.3 KG
20 Meters video and power cable
For bus and truck rear view camera
Weight:0.71
